ENDURO COMPUTER MOUNT

Regular Price
$16.00
Sale Price
$16.00
Regular Price
Out of Stock
Unit Price
per

Computer: GARMIN

Fit: TYPE A

Finish: BLACK

1040G

Details

Sticks Like $%*? To a Blanket!

Self-adhesive computer mount using 3M VHB tape (very high bond)

Designed to fit onto your top tube behind your stem for maximum protection and less distraction.

FIT OPTIONS

Type A for flat or slightly curved top tubes  Maximum curve of up to 3mm drop 12mm from the centre line. Most carbon and aluminium bikes require type A. The base of Type A's has a flat centre with curved 'wings' that flex to the top tube profile, including going all the way to flat.
Some customers have been surprised that the Type A has a pronounced curve to the base, be assured that it will flex to flat. Type A has a single dot on the spine.

Type B for round and heavily curved top tubes. Works on round tubes of 34mm, smaller diameters will require the mount being clamped in place overnight in order to ensure a good bond. Type B has 2 dots on the spine.



Supplied with alcohol wipe to clean the area to be attached to.

Manufactured in-house in nylon using Multi Jet Fusion additive manufacturing and shot peened for surface toughness and quality.

CERAKOTE COLOUR OPTIONS

Currently available for Garmin Type A only
Cerakote is a ultra thin ceramic coating which is hydrophobic, chemical and scratch resistant.

Top left to bottom right in image:

Blue Titanium (metallic flecks)
Tequila Sunrise (metallic flecks)
Burnt Bronze (metallic flecks)
Firehouse Red (satin)
Magenta (flat matte)

Testing has shown that the coating on the enduro mounts are resistant to wear, however the tip of the little Garmin engagement tabs ( at 3 and 9 o'clock) will wear down to black.



IMPORTANT - Check there is clearance from the underside of bars/stem to the top tube:










Sticks Like $%*? To a Blanket!

Self-adhesive computer mount using 3M VHB tape (very high bond)

Designed to fit onto your top tube behind your stem for maximum protection and less distraction.

FIT OPTIONS

Type A for flat or slightly curved top tubes  Maximum curve of up to 3mm drop 12mm from the centre line. Most carbon and aluminium bikes require type A. The base of Type A's has a flat centre with curved 'wings' that flex to the top tube profile, including going all the way to flat.
Some customers have been surprised that the Type A has a pronounced curve to the base, be assured that it will flex to flat. Type A has a single dot on the spine.

Type B for round and heavily curved top tubes. Works on round tubes of 34mm, smaller diameters will require the mount being clamped in place overnight in order to ensure a good bond. Type B has 2 dots on the spine.



Supplied with alcohol wipe to clean the area to be attached to.

Manufactured in-house in nylon using Multi Jet Fusion additive manufacturing and shot peened for surface toughness and quality.

CERAKOTE COLOUR OPTIONS

Currently available for Garmin Type A only
Cerakote is a ultra thin ceramic coating which is hydrophobic, chemical and scratch resistant.

Top left to bottom right in image:

Blue Titanium (metallic flecks)
Tequila Sunrise (metallic flecks)
Burnt Bronze (metallic flecks)
Firehouse Red (satin)
Magenta (flat matte)

Testing has shown that the coating on the enduro mounts are resistant to wear, however the tip of the little Garmin engagement tabs ( at 3 and 9 o'clock) will wear down to black.



IMPORTANT - Check there is clearance from the underside of bars/stem to the top tube:










Weight:

Material: MJF Nylon PA12 - manufactured in house

Use the message facility -> if you have question that isn't answered here.

Will the Enduro Mount stick to frame protection coverings? Sticks to Invisframe, Dyed Bro, and AMS frame protection - others not tested.

Can I remove it without damaging paintwork? Yes, the adhesive pad comes off in one piece, like putty. See instructions section.

I ordered type A but it more curved than I expected. Will it fit my frame which has a flat top tube? Yes, the 'wings' will flex to flat. See instructions.

I had a crash and the mount broke. It's a balancing act between the mount breaking and the tabs of the computer breaking. We think it's better than the mount breaks rather than a £300 computer. Using Garmin 1000s series computers greatly increases this risk due to the extra width being exposed.

If you have an accident and the mount breaks get in touch to find about our crash replacement scheme.

When fitting the adhesive needs a temperate of at least 20 degrees C to cure properly. After fitting the mount should be left overnight before riding.

See videos in image section of install and uninstall instructions. Also available here.

Recommended for smaller series computers no larger than Wahoo Element Roam, Garmin 500 series. Larger computer are vulnerable to knee knocks. As with any mount, in case of a crash, we recommend looping the computer's tether around the top tube.

To remove, pry the mount off from one end. The adhesive pad should remain in one piece but cannot be reused. Replacement VHB pads are available here. It helps to heat with a hairdryer or leave in a warm room beforehand.

We hate it went a product has to be junked when a part can't be replaced. If spares aren't listed then message us -> and we'll see if we can help.

Replacement VHB pads are available here
