Specifically designed to work with tubeless systems.
76 Projects' HI FLOW valves have 4x the air throughput and a redesigned core that helps prevent sealant build-up.
Tubeless bike tyres and rims were introduced 20 years ago yet tubeless systems still use the Presta valve standard from the 1890's. The clearances in a Presta valve are smaller than the holes that the sealant is supposed to be able to block so it's no surprise that the valves get clogged.
- 'No Clog' internals - Greatly increased clearances prevent sealant build up*.
- 4x greater air flow (compared to Presta) - Fill the tyre faster to help seat and seal the bead.
- Works with lever lock Presta pump heads. An adapter may be required for other pump head types, see below for more details on compatibility.
- Sealant can be directly injected through the valve centre. See pump compatibility section below for more details.
- Just 9 grams a pair.
- High precision CNC machined aluminium.
- Spare parts available here.
- Sizes 0 & 1 Compatible with rim protection inserts.
- Compatible with push-on CO2 inflators, adapter required for screw-on inflators.
Weight: 9 grams - size 2
Material:
Use the message facility -> if you have question that isn't answered here.
We hate it went a product has to be junked when a part can't be replaced. If spares aren't listed then message us -> and we'll see if we can help.
HI FLOW VALVE OVERVIEW
Despite fitting in the same size valve hole and using the same pumps as presta Hi Flow valves have a unique precision CNC'd construction which enables 4x the airflow.
HI FLOW 'NO CLOG'
Hi Flow Valves valves feature a unique hollow precision CNC'd stainless steel valve core. In combination with the wider 'transfer chamber' section it means that 4x the air flow is achieved versus a presta valve.
The greatly increased clearances also mean that clogging is far less likely. Whereas the clearances in a Presta valve are smaller than the holes that sealant is supposed to be able to block so it's no surprise that they get clogged.
VALVE SIZES
Size 0 - 09-20mm rim height* Compatible with rim inserts - MTB
Size 1 - 15-35mm rim height* Compatible with rim inserts - MTB / GRAVEL / ROAD
Size 2 - 30-50mm rim height* - GRAVEL / AERO ROAD
Size 3 - 45-65mm rim height* - DEEP SECTION AERO
Size 4 - 60-85mm rim height* - DEEP SECTION AERO
*unlike normal valves our HI Flow valves are specified by the rim height rather than the valve length.
ADDING SEALANT
Sealant may be added directly through the hollow valve core via a tube with an internal diameter of 5mm. However, we always recommend unseating a section of tyre and putting sealant directly in. That way the sealant level can be observed. Because of the hi-flow nature the direct method is much easier than with presta valves.
See video for tips on adding sealant.
*Some sealants with very large particles such as Silca Ultimate may still clog in some circumstances. For these sealants we recommend added directly to the tyre rather than through the valve.
PUMP COMPATIBILITY
Our Hi Flow valves are not Presta but are designed to be work with Presta style lever lock style pump heads .
The hi flow design means that some screw-on and push on pump heads do not fit well or at all. We offer 2 adapter options for those pump head types:
Adapters are available to fit Presta or Schrader style pump heads. Schrader version supplied if you select the adapter option on this page. The Schrader option is much smaller than Presta so we recommend that if your pump has Schrader head option. Separate adapters can be found on this page.
*No adapter required for One Up EDC pump.
**Topeak Smart Heads or others that use one opening for both Presta and Schrader will require an adapter.
Installation Guide (full version)
